Description

PRODUCT INFO

• Two mounting modes: horizontal and vertical
• Flood beam (asymmetric lens)
• Cables with DT connector not included (see #59101 male, #59102 female)
• Over- and under-voltage protection
• Reverse-polarity protection

SPECIFICATIONS

• Certification: CISPR 25 Class 3, EMC, ECE R10, IP67, IP6K9K
• Power: 108 W (36 LEDs)
• Voltage: DC 10–30 V
• Current: 4 A @ 12 V; 2 A @ 24 V
• Luminous Flux: 11 160 lm
• Color Temperature: 5 500 K
• Operating Temperature: –40 °C to +50 °C
• Dimensions: 160 × 111 × 93 mm (6.3″ × 4.4″ × 3.7″)
• Materials: Aluminum housing; UV-resistant polycarbonate lens; stainless-steel mounting bracket

VEHICLE COMPATIBILITY
Agricultural vehicles, on-road vehicles, mining equipment, and forklifts.
